Simcoe Skies Astronomy

M92 - Globular Cluster

Be sure to scroll down to see all images

M92
M92 Cluster - NGC 6341
First try on this Cluster

Magnitude: 7.5
Location: Hercules
Date: Sept 18/04
Exposures: 22 best of 65
Exposure length: 5 seconds
Amp on setting: OFF
Brightness: 100
Gain: 40

Notes: Annoyingly out of focus. After this, I read up on focusing and tried various solutions. I found the "dowel & diffraction spike" method to produce crisper images than a Hartmann mask.

M92
Another try
2nd Attempt about a week later

Magnitude: 7.5
Location: Hercules
Date: Sept 26/04
Exposures: 30
Exposure length: 6 seconds
Amp on setting: OFF
Brightness: 100
Gain: 40

Notes: Much better focus this time, although polar alignment was suffering (again). After enough of these, I concluded that my polar alignment was off because I was setting up on a wooden deck - and the redistribution of weight and deck "flex" when I walked away from the scope would instantly throw my alignment out (I could see the image shift around in the preview screen when I changed my location on the deck).
